Lenovo ThinkCentre M90q Gen 5 Tiny Desktop Computer
Lenovo M90q Gen 5 Overview
By Photo's
Steven Wong
The Lenovo ThinkCentre M90q Gen 3 Tiny Desktop Computer proves that you don't need a huge, bulky system to stay productive. Designed for home and office environments with vPro Enterprise support, this computer smoothly multitasks demanding applications with a 14th generation 2 GHz Intel Core i9 24-Core processor with 32GB of DDR5-5200 memory and a secure Opal encrypted 512GB NVMe PCIe 4.0 SSD.
Connect to compatible high-speed wireless networks using the built-in Wi-Fi 6E (802.11ax) support or through the Gigabit Ethernet port. Quickly transfer massive files using the 20 Gb/s USB-C 3.2 Gen 2x2 port and 10 Gb/s USB-A 3.2 Gen 2 ports. Use the available USB-A 3.2 Gen 1 ports for peripherals such as the included mouse and keyboard. Windows 11 Pro 64-bit preinstalled.
Performance
The Intel Core i9-14900 processor powers applications with eight Performance cores with a 5.4 GHz Max Turbo frequency while the 16 Efficient cores handle background tasks. This processor provides rich visuals with integrated Intel UHD 770 Graphics.
Compact Design
Conserve space by using the included stand to place the ThinkCentre M90q Gen 5 vertically.
Network Connectivity
Integrated Wi-Fi 6E support delivers fast and reliable wireless connections to compatible networks. A Gigabit Ethernet port is also available for wired connections.
Multi-Monitor Support
Enhance your multitasking efficiency by connecting up to three displays through the HDMI and two DisplayPort ports.
Upgrade Ready
Install up to 64GB of DDR5 memory across two SO-DIMM slots. Two M.2 SSD slots are available for storage. A low-profile expansion card may be installed into the PCIe 4.0 x8 slot.
Windows 11 Pro
Microsoft simplified the design and user experience with Windows 11. It has a modern, clean design with a new Start Menu position. Snap Layouts, Groups, and Desktops allow you to multitask with ease. Microsoft has also integrated some of their apps, such as Microsoft Teams. The redesigned Microsoft Store makes it easier to look for supported apps. The Pro version of Windows 11 includes all the features that Windows 11 Home offers plus many designed specifically for business users, including Hyper-V virtualization, BitLocker disk encryption, and remote desktop access.
UPC: 198153869428
Items Included
- Lenovo ThinkCentre M90q Gen 5 Tiny Desktop Computer
- Power Adapter
- USB Keyboard
- USB Mouse
- Limited 3-Year Manufacturer Warranty
Additional Resources
Lenovo M90q Gen 5 Specs
Key Specs
| Operating System |
Windows 11 Pro
|
| Processor |
Intel Core i9-14900 (14th Gen)
|
| GPU |
Intel UHD Graphics 770
|
| Installed RAM |
32 GB
|
| Total Installed Storage |
512 GB
|
| External Bays |
No
|
| Inputs/Outputs |
1x USB-C 3.2 Gen 2x2
4x USB-A 3.1/3.2 Gen 2 2x USB-A 3.0 / 3.1/3.2 Gen 1 |
| Display I/O |
1x HDMI 2.1a
3x DisplayPort 1.4a |
| Audio I/O |
1x 1/8" / 3.5 mm Headphone/Microphone Input/Output
|
| Wi-Fi |
Wi-Fi 6E (802.11ax) with MU-MIMO Support (2 x 2)
|
| Bluetooth |
5.3
|
| Keyboard |
USB Full-Size Keyboard
|
| Pointing Device |
USB Mouse
|
| Power Supply |
230 W with Barrel/Proprietary
|
Performance
| Chipset |
Intel Q670
|
| Processor |
Intel Core i9-14900 (14th Gen)
|
| CPU Socket |
LGA 1700
|
| CPU |
24-Core:
2 to 5.4 GHz Performance (8 Cores) 1.5 to 4.3 GHz Efficiency (16 Cores) |
| Dedicated AI Cores |
No
|
| L3 Cache |
36 MB
|
| Graphics Type |
Integrated
|
| GPU |
Intel UHD Graphics 770
|
| Installed RAM |
32 GB
|
| RAM Type |
5200 MT/s DDR5 SO-DIMM
|
| RAM Configuration / Capacity |
1x User-Replaceable 32 GB / 2 Slots Supporting up to 64 GB
|
| vPro Support |
Yes
|
Storage and Expansion
| Total Installed Storage |
512 GB
|
| Storage Drive Type |
1x 512 GB / M.2 NVMe SSD
|
| Storage Expansion |
1x M.2 Slot 2280 [Available]
|
| PCI Expansion |
1x PCIe 4.0 x8 (Available)
|
| Optical Drive |
No
|
| External Bays |
No
|
Inputs / Outputs
| Inputs/Outputs |
1x USB-C 3.2 Gen 2x2
4x USB-A 3.1/3.2 Gen 2 2x USB-A 3.0 / 3.1/3.2 Gen 1 |
| Display I/O |
1x HDMI 2.1a
3x DisplayPort 1.4a |
| Audio I/O |
1x 1/8" / 3.5 mm Headphone/Microphone Input/Output
|
| Network I/O |
1x RJ45 (Gigabit Ethernet)
|
| Built-In Speakers |
1x 2 W
|
| Built-In Microphones |
No
|
| Media/Memory Card Slot |
No
|
Communications
| Wi-Fi |
Wi-Fi 6E (802.11ax) with MU-MIMO Support (2 x 2)
|
| Bluetooth |
5.3
|
Keyboard & Mouse
| Keyboard |
USB Full-Size Keyboard
|
| Pointing Device |
USB Mouse
|
General
| Power Supply |
230 W with Barrel/Proprietary
|
| Input Power |
100 to 240 VAC, 50 / 60 Hz
|
| Certifications |
ENERGY STAR, EPEAT, ErP, RoHS, TCO Certified
|
| Dimensions |
7.2 x 7 x 1.4" / 182.9 x 179 x 36.5 mm
|
| Weight |
2.76 lb / 1.25 kg
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
